Magnum Hydraulic Tubing / Casing Power Tongs 5-1/2"

5-1/2" • V8 BU Hydraulic Tubing / Casing Power Tongs

Magnum Manufacturing has successfully mastered the design and manufacturing processes of creating a world class power tong. By decreasing the weight and substantially increasing the power, Magnum Manufacturing out performs the torque to weight ratio of any competitor. Constructed of premium quality materials, Magnum’s unique system delivers safe, efficient, and reliable performance on every job.

FEATURES:

    • Highest Torque-to-Weight ratio in the world (vs comparable tongs)
    • New patent pending jaw technology- pivotal or sliding jaw modes
    • Runs conventional and CRA tubulars
    • Backup tong available
    • Interchangeable gear design
    • New Magnum safety door
    • Integrated Automatic Shutdown (ADS™)
Magnum Manufacturing located in Houston TX. Buy from experience.
  • Throttle Lockout Device (TLD™)
  • Four speed standard
  • Interchangeable Jaws with Backup

Patent Pending

Request Quote

MODEL:
5-1/2" – V8 BU
(in) 5-1/2"
(mm) 139.7
Max Torque: 30,000 ft/lbs
Gear Speeds:
High 103 RPM
Low 9 RPM
Flow Rate: 55 GPM
Approx Weight:
(lbs) 1,350
(kgs) 612
Approx Weight w/ backup:
(lbs) 2,600
(kgs) 1,179
Width:
(in) 24
(mm) 609.6
Back-up Width:
(in) 34.75
(mm) 882.65
Length:
(in) 50
(mm) 1,270
Back-up Length:
(in) 53.5
(mm) 1,270
